Custom Lithium Ion Battery Pack

3.7V 1800mAh Lithium Polymer Battery for Military Fiber Splicing Equipment

  • Model number:01DQ0096-01

  • Nominal voltage:3.7V

  • Nominal capacity:1800mAh

  • Battery cell:883650/3.7V/1800mAh

  • Dimension:81.7*60.1*13.2mm(Max)

  • Application:military equipment

Product Detail

Product number: 01DQ0096-01

Cell model:883650/3.7V/1800mAh

Battery specification: 883650-1S1P/3.7V/1800mAh

Nominal voltage:3.7V

Nominal capacity:1800mAh

Charging voltage: 4.2V

Charging current: ≤1.8A

Discharging current: 1.8A

Instant discharging current: 2A

End-off voltage: 3V

Internal resistance: ≤180mΩ

Battery weight: 0.2Kg

Product dimension: 81.7*60.1*13.2mm(Max)

Charging temperature:0~45℃

Discharging temperature: -20~60℃

Storage temperature: -20~35℃

Battery case: zinc alloy

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, etc.

Application field: military equipment

*
*
*
