Product number: 40AQ010-03
Cell model: 18650-3350 mah -3.6V
Battery specifications: 18650-7S6P-20.1AH-25.2V
Product size: 293mm *250mm *25mm
Nominal voltage: 25.2V
Nominal capacity: 20.1A
Rated capacity: 19.2A
Charging voltage: 29.4V
Charging current: 10A
Discharge current: 10A
Discharge cut-off voltage: 17.5V
Finished internal resistance: ≤200m ω
Battery weight: About 4.2kg
Charging temperature: 0~+45℃
Discharge temperature: -20~+60℃
Storage temperature: -20~+45℃ (less than 1 month); -20 ~ 35 ℃(less than 3 months); -10~+25℃ (less than 12 months)
Battery package: metal case;
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, over temperature protection, etc
Application: Special laptop
1.Metal shell is simple and reliable,and is easy to be installed.
2.RS485 communication protocol
3.Output terminal: Use GB UL wire output mode to increase the conductivity reliability.
4.Battery protection management: Adopt imported brand protection chips with high stability, high precision monitoring and accurate control, to eliminate potential safety hazards to the maximum.
5.The battery pack is safe, has good discharge performance and long cycle life.
6.The battery pack has a long cycle life and conforms to the values of low-carbon, energy saving and environmental protection.
