Product Detail

Product number: 35AQ484-01

Cell model:70104179-3.7V-9.6Ah

Battery specification: HPB-566-02(70104179-7S3P-28.0Ah-25.9V)

Nominal voltage:25.9V

Nominal capacity:28Ah

Charging voltage: 29.4V

Charging current: ≤25A

Discharging current: 30A

Instant discharging current: 3000A (starting current)

End-off voltage: 16.0V

Internal resistance: ≤50mΩ

Battery weight: 20.0kg

Product dimension: 320.0±0.2L*175.0±0.2W*123.0±0.2H(mm)

Charging temperature:0~45℃

Discharging temperature: -40~55 ℃

Storage temperature: -20~45 ℃

Battery case: MIL

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, etc.

Application field: outdoor special products


Product features

1. Current: maximum 40A discharge.

2. Low temperature, high current, continuous discharge

3. Cell characteristics: low temperature rate lithium iron phosphate battery pack

4. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.

*
*
*
