26650 32V 20Ah Inspection Robot Lithium Iron Phosphate Battery

Product Number: 01DQ0164-03

Cell MODEL: C40-20Ah-3.2V

Battery specification: C40-10S1P-20Ah-32V

Product size: 230*160*92mm (Max)

Nominal voltage: 32V

Nominal capacity: 20Ah

Finished internal resistance: ≤200mΩ

Charging voltage: 36V

Charging current: ≤9.5A

Discharge current: ≤12A

Discharge cut-off voltage: 20V

Battery weight: 4000g

Charging temperature: 0 ~ 45℃

Discharge temperature: -20 ~ 60℃

Storage temperature: -20 ~ 35℃

Battery package: Blue PVC heat shrink film

Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overtemperature protection, overcurrent protection,ESD protection, etc.

Application: Inspection robot, intelligent robot, AGV, robot

Product Features

1.Blue PVC heat shrink film package is simple and reliable,and easy to install;

2.The battery pack is assembled with special battery cell bracket, protected by epoxy plate and connected by special nickel sheet, which has good shock and impact resistance.

3.National standard wire output mode: Anderson connector inserting can increase conductive reliability;

4.Data communication management: Use 485 communication for accurate data transmission, accurate temperature control, real-time battery status monitoring and control to minimize safety risks;

5.BMS communication uses optocoupler isolation. The product supports 485 bus for customer optional communication and networking.The communication baud rate is 9600bps;

6.The battery pack has long cycle life, in line with low carbon, energy saving, environmental protection value concept.
