Low Temperature Charging and Discharge 26650 25.6V 23.1Ah Inspection Robot LiFePO4 Battery
Product Number:
01DQ0164-02
Nominal voltage:
25.6V
Nominal capacity:
21.7Ah
Battery Configuration:
26650-8S7P
Dimension:
285 × 163 × 90 mm (Max)
Application:
inspection robots, AGVs, and intelligent robotic equipment
RS485 Communication Support, -40℃ Low Temperature, Long Cycle Life
Product Overview
This battery is designed for inspection robots, AGVs, and intelligent robotic equipment, supporting continuous operation in harsh industrial environments. Featuring RS485 communication, stable low-temperature performance, and reliable high-capacity output, it ensures dependable long-duration operation for demanding robotic applications.
Electrical Specifications
| Attribute | Parameter |
|---|---|
| Product Number | 01DQ0164-02 |
| Cell Model | 26650-3300mAh-3.2V |
| Battery Configuration | 26650-8S7P |
| Nominal Voltage | 25.6V |
| Nominal Capacity | 21.7Ah |
| Rated Energy | 555.52Wh |
| Charging Voltage | 28.8V |
| Standard Charging Current | ≤10A |
| Standard Discharge Current | ≤20A |
| Discharge Cut-off Voltage | 16V |
| Internal Resistance | ≤100mΩ |
Mechanical & Environmental
| Attribute | Parameter |
|---|---|
| Charging Temperature | -20 ~ 45℃ |
| Discharge Temperature | -40 ~ 60℃ |
| Storage temperature | -20 ~ 35℃ |
| Dimensions | 285 × 163 × 90 mm (Max) |
| Weight | 5800g |
| Output Type | Anderson Connector |
| Battery Case | Blue PVC Heat Shrink Film |
| Communication Protocol | RS485 |
| Protection System | Short Circuit Protection, Overcharge Protection, Over-discharge Protection, Overtemperature Protection, Overcurrent Protection, ESD Protection |
We support flexible customization based on your project requirements, including:
- Voltage range: 3.2V – 72V
- Capacity range: 100mAh – 100Ah
- Electrical performance design: Charge/discharge parameters, C-rate, internal resistance, temperature performance
- Mechanical design: Appearance, dimensions, housing material, and integrated structural engineering
- BMS design: Battery protection, cell balancing, and communication protocols (SMBus / I2C / UART)
Get a Custom Battery Solution
Tell us about your project needs. Our engineers will provide a tailored battery solution and quotation within 24 hours.
