Product number: 08DQ0001-03
Cell model: 874969-3500MAH-3.7V
Product size: 72*50*9.2mm (Max)
Nominal voltage: 3.7V
Nominal capacity: 3500mAh
Product internal resistance: ≤200mΩ
Charging voltage: 4.2V
Charging current: ≤1.7A
Discharge current: ≤3.5A
Discharge cut-off voltage: 2.8V
Battery weight: 75G
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60 ℃
Storage temperature: -20 to 35 ° C
Battery packaging: simple packaging
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, etc.
Application: Portable devices, Bluetooth speakers
1.The package is simple, reliable and easy to be installed.
2.Connector output terminal: The MOLEX plug is used to output the connector to increase conductive reliability.
3.Battery protection management: Adopt dedicated lithium battery protection chip with good stability, high precision monitoring and precise control, to eliminate security risks to the maximum.
4.The battery pack has good safety, nice discharge performance and long cycle life.
5.The battery pack has a long cycle life and conforms to the values of low-carbon, energy saving and environmental protection.
