Battery Ah Calculation-Meaning, Calculating, And Cycle Life

May 20, 2020   Pageview:397

Ah is a common term that you can hear whenever you go to buy a battery for a mobile or a laptop. Basically, Ah stands for amp hour. It is an amount of a battery's energy storage capacity. If you are wondering a battery as a small fuel storage tank, then you should know Ah is a way to measure how much fuel the battery holds an amp-hour. Ah is a unit for measuring electric power over time. Also, Ah is commonly used to describe the total amount of energy a battery can store at one time. It's a nice way to distinguish the strength and capacity of a battery. The higher the Ah, the longer the battery will last.

When you want to know how long a battery will last, it's significant to consider not just how many hours it will run in continuously, but also the full lifespan of a battery, called "cycle life."

What the AH mean on a battery?

The measure of current a battery can supply for a particular period is known as an Amp Hour (Ah). There are also sub-units of the Amp Hour, like the Milliampere-Second (mA-s) and Milliampere-Hour (much or mAh).

When you look at the battery, there are two main ratings mentioned in it. One is the voltage rating, and the other is the Ah or mAh rating for it. Voltage rating is the maximum voltage that is supplied by the battery in terms of volt. The other specification is for battery capacity, which tells the storage capacity of the battery in mAh, which is milliampere hours is the product of current expression Milli amperes multiplied by time represented in hours.

24V Emergency Starting Power Supply,Low Temperature Large Current
Low Temperature Large Current 24V Emergency Starting Power Supply Battery specification: 25.2V28Ah (lithium battery) , 27V300F (supercapacitor pack) Charging temperature:-40℃~+50℃ Discharging temperature: -40℃~+50℃ Starting current: 3000A

AH = Current(A)x Time(H)

When a manufacturer says that this is a 12 volts 3000mah battery, then what he means by that is the battery can supply 12 volts for one hour when the load is drawing 3000 milliamp hours from it. Similarly, when the load is drawing a hundred milliampere from the battery, then the battery can be supply voltage to it for 30 hours. And when the load is drawing 200 milliamperes from the battery, then the battery can supply 12 volts to it for fifteen hours in that way. You can calculate the battery backup time when you have the load current mentioned for you. And when you know how much current, the load is going to draw from the battery. Then you can easily calculate the battery backup time using the maturity.


How do you calculate battery Ah?

To calculate a battery's life, we have to divide the capacity of the battery with the current required by the object. For instance, imagine that you have two batteries on your phone, one with a capacity of 1000 mAh and one with a capacity of 2000 mAh. Your phone requires a current of 200 mAh to function the first battery, i.e., 1000 divided by 200 equals 5. And for second, the battery will power the phone for ten hours as it has doubled the capacity of the first. You may get a longer battery life, but a longer charge time is also needed.

Low Temperature High Energy Density Rugged Laptop Polymer Battery 11.1V 7800mAh
Low Temperature High Energy Density Rugged Laptop Polymer Battery Battery specification: 11.1V 7800mAh -40℃ 0.2C discharge capacity ≥80% Dustproof, resistance to dropping, anti - corrosion, anti - electromagnetic interference

When you buy a deep cycle battery, you'll see different numbers listed on the batteries label and first deep cycle application. The companies like the U.S. Battery company listed clearly, like at the 20-hour rate right on the label, i.e., six volts. Power is a length of time or a measurement tool used to understand how many amps you can discharge from any battery over the amount of time. A realistic amount of time would say maybe 20 hours of usage. Some companies claim to provide batteries that have a slower discharge rate than others. But it is not true for every type of battery. The discharge rate is also a factor that determines the battery's life cycle. Hence, we need to keep the discharge rate consistent as well.

How long will a 100 Ah battery last?

If a battery has 100Ah and it can deliver 5 amperes per hour for 20 hours. The Ah rating is determined by over 20 hours for most of the batteries.

In order to find out the measure of power an object draws from a battery, the important thing is that not only the amp hours of the battery are determined, but also the voltage being drawn by the battery.

FORMULA: watts = volts x amps

If a battery has a rating of amp hours, we can also rewrite it as watts divided by volts, which equal to the amps, and then we can determine the time.

Let us consider an example, a LED light with 1.2-watt power working on a battery of 12 volt, and it uses 0.1 amps current. We can calculate it as 1.2/12 = 0.1. In this scenario, a 12 volts 100Ah battery would last for 1000 hours approximately.

Now, let's say we have an inverter say that inverter is 400 watts, and how long we can run this battery with a given load. What you do is take the 400-watt inverter and let's say 12-volt inverter, divide the 400 by 12, and that gives you amps, which is 33.3 amps. Okay, so we know we have a 33.3 amps inverter at full load. Remember, we have 105/33.3, and that gives you roughly about three hours of runtime.

Conclusion:

An amp-hour (Ah) tells you the measure of current a battery can provide over a certain period, and a rating which is usually in amp-hours or milliamp-hours is used to depict how long a battery can run in a given amount of current. Amp-hours can be calculated by multiplying the number of amps (A) a battery provides divided by the discharge time, which is in hours (h). So, if a battery provides 10 amps of current for 10 hours, it is 10 amps × 10 hours = 100 Ah battery.
