Which one is better, lithium iron phosphate battery or ternary lithium ion battery?

May 10, 2019   Pageview:555

Lithium iron phosphate battery is a lithium ion battery using lithium iron phosphate as anode material. The positive electrode material of lithium ion battery includes lithium cobalt oxide, lithium manganite, lithium nickelate, ternary material, lithium iron phosphate, etc. Lithium cobalt oxide is the most popular anode material of lithium ion material at present.


Ternary polymer lithium ion battery is a lithium ion battery using lithium, nickel, cobalt, and manganese ternary material as anode material. There are many kinds of anode materials of lithium ion material, those popular materials include lithium cobalt oxide, lithium manganite, lithium nickelate, ternary material, lithium iron phosphate, etc.




Lithium iron phosphate battery


Lithium iron phosphate battery is a lithium ion battery using lithium iron phosphate as anode material. Its feature is excluding noble element such as cobalt, etc. There is no incoming material issue because the raw material is inexpensive, and phosphorus and iron have abundant resources on earth. With suitable working voltage (3.2V), large capacitance under unit weight (170mAh/g), high discharge power, rechargeable and long cycle life, it also has good stability under battery heating and high temperature environment.


Advantages:


Compared with recent market normal lithium cobalt oxide and lithium manganite battery, lithium iron phosphate battery has at least five advantages: higher security, longer cycle life, no any heavy metal or rare metal (low cost of raw material), support fast charge and wider working temperature.


Disadvantages:


There are some disadvantages on performance of lithium iron phosphate battery, such as low tap density and compaction density, which results in lower energy density; The battery yield and consistency is poor because of high material preparation cost and manufacture cost; Product consistency is poor; Even have an intellectual property issue.




Ternary polymer lithium ion battery


Ternary polymer lithium ion battery is a lithium ion battery using Ni-Co lithium manganite as ternary anode material. Just as Ouyang Minggao from Tsinghua University saying: the ternary material in this survey means that the positive electrode use ternary, while the negative electrode is graphite. This is called ternary power battery. During actual application, there is a material called lithium titanate, which its positive electrode use ternary, negative one is lithium titanate. It will be safer and have longer cycle life, but it does not belong to ternary material.


Advantages:


Ternary lithium ion battery has high energy density, and its cycle performance is better than normal lithium cobalt oxide. Nowadays, with the improvement of the formula and structure, the Nominal Voltage of the battery reaches 3.7 V, and the capacity is far higher than that of lithium cobalt oxide battery.


Disadvantages:


Ternary power lithium ion battery includes lithium nickel cobalt aluminate battery, Li-NiCoMn Lithium ion battery etc. The disadvantage of it is poor high temperature security because of unstable high temperature structure of Alnico, and monomer gas issue due to high pH value, which is very dangerous. Last but not least, it cost a lot.


In summary, after brief comparison, ternary polymer lithium ion battery does have better performance than lithium iron phosphate battery, but why its development is impeded? Above all, ternary polymer lithium ion battery will be better.


Accord with material, cell can mainly divide into lithium iron phosphate and  manganese-bearing material (include lithium cobalt, ternary material, etc.)


The Nominal Voltage of lithium iron is 3.2-3.3V, while manganese-bearing is 3.6-3.7V, which is the most obvious distinction.


The advantages of lithium iron system: long theoretic cycle life, theoretically good charge and discharge performance (why is theoretic? Please read forward.)


The advantages of ternary system: high energy density, good low temperature performance, small volume, good discharge linearity


The disadvantages of lithium iron: large volume, heavy weight, bad discharge linearity, poor low temperature performance


The disadvantages of ternary system: lower cycle life, poor cycle life under high temperature.


Many articles introduce lithium iron and refer that the cycle life is at least 1500, and it’s also normal to be 2000-3000. If this is the truth, the advantages of lithium ion will be obvious, but there is huge difference between ideal and reality. I have seen a lithium iron cell produced by a national big factory. Its actual cycle life is around 100, barely enough to compare with plumbic acid, which is theoretically 2000, but actually is 1/20. It is a negative example, but not a representative. Based on recent experience, lithium iron with good quality will have better cycle life, but there is still far lower than theoretic standard, even negligible.


So it is unreliable to select lithium iron only based on cycle life.


Low temperature performance


Low temperature performance is an inherent problem of lithium iron. It can only reach 75% of the capacity in summer at -0~5℃ in Jiangsu and Zhejiang areas in winter, and even lower under high-current condition for high power vehicle. While ternary lithium ion battery can reach 90% of the capacity in summer at the same temperature. It is lightly affected by the temperature, but if you use in further northern area, it will be much lower. Customers from different districts need to consider this issue while choosing lithium ion material.


Discharge linearity


In short, discharge linearity means the relationship between electric quantity and voltage.


Due to material properties, lithium iron has a high voltage state, a maintenance state and a low voltage state. The voltage drops very fast under high voltage state and low voltage state, but very slow under maintenance state. The final result is that the lithium iron battery with fully charge loses several V capacity during vehicle starting, then enters maintenance state and decreases very slowly. After discharging about 80%-90% capacity, it is into low voltage state. On one side, this discharge feature is good because the voltage is very stable during discharging state. On the other hand, the user cannot judge the rest capacity easily by data presentation of the voltage, may need to push the vehicle on the way.




Overcharge and over-discharge performance


One of the advantages of lithium iron (theoretically) is resistance of overcharge and over-discharge. Generally speaking, there is no danger to overcharge lithium iron to 5V in a short time, and no obvious effect on performance after discharge redundant current immediately. Manganese lithium ion battery has distinct overcharge reaction to 5V, which damage the cell terribly.


Lithium iron can back to normal state after over-discharging to 0V (the performance will decrease mildly), while ternary system is scraped after over-charging to 0V.


Based on the above, lithium iron has better performance of overcharge and over-discharge.


Actually, due to the lithium iron sharp curve of charging and discharging under high voltage state and low voltage state, only seldom electricity capacity can take apparent changes on voltage. Actual application is totally different from the literal meaning.


Compared ternary system cell with lithium iron having the same capacity, the voltage of lithium iron will increase very fast and scrap earlier than manganese-bearing during the cascade overcharging test after fully charging. So does the over-discharging test. The minimum limitation of overcharging of a single battery is 0V, but battery pack will never stop even after over-discharging to 0V, and the cell will be under negative voltage rapidly, which results to scrap.


Volume


Lithium iron doesn’t have advantage of volume. With the same size, lithium iron only has a capacity of 10AH, while ternary system over 15AH. This leads to big difference to recent high power electric motorcycle.


Taking the different size of electro car for example, it needs to install around 72V80AH for lithium-iron battery, but also needs to refit a lot for 100AH one. If replace with lithium ternary battery, it’s easy to install 150AH battery, and even not difficult for 200AH. But lithium iron lack of advantages for user demand of long distance and high current discharge performance. Not only charging current, but also endurance mileage is far below the acquirement.


Actual cycle life


If the quality of lithium iron is good, one-year attenuation can control within 5%, and the next year is 15%. As for ternary material, one-year attenuation can control within 7-10%, and the next year is 20-25%. These data analysis may be a little different from actual application, because of the affect from usage load and operating frequency.


Above all, the performance of lithium iron can be described as follow: bigger size, poor low-temperature performance, but can maintain stable decay rate within cycle life. Normally, it can be used for around 5 years. Ternary system features are small size, bigger volume, no obvious difference performance in winter, large initial capacity, better endurance mileage than lithium iron, apparently smaller capacity in final-stage. Normally, it can be used for around 3 years.
