Product number: 36AQ279-01
Battery specification: 603453CL-1S1P/3.7V/1200mAh
Charging voltage: 4.2V
Charging current: ≤600mA
Discharging current: 240mA
Instant discharging current: 1A（3~4S）
End-off voltage: 2.5V
Internal resistance: ≤150mΩ
Battery weight: 27g
Product dimension: 53*34.5*6.5（mm）
Discharging temperature: -40～60℃
Storage temperature: -20℃～+23℃（≤12 months）
Battery case: PVC
Lithium ion battery protection: overcharge protection, over-discharge protection, overcurrent protection and short circuit protection.
Application field: portable electronic products, noise-canceling headphones, smart helmets, etc.
It has small power consumption and long storage time.
It can discharge at -40℃ low temperature.
Cell size can be customized to meet the structure requirement.
Ultra-thin design can increase the finished product aesthetics.
