Product number: 36AQ504-01
Battery specification: 602338-1S2P/1100mAh/3.7V
Charging voltage: 4.2V
Charging current: ≤500mA
Discharging current: 200mA
Maximum discharging current: 2A,3~4S
End-off voltage: 3.0V
Internal resistance: ≤100mΩ
Battery weight: 30g
Product dimension: 42*24*12.5（mm）
Discharging temperature: -10～60℃
Storage temperature: -20～20℃ (less than 12 month)
Battery case: PVC
Lithium ion battery protection: short circuit protection, overcharge protection, over discharge protection, over current protection.
Application field: Analytical balance, precision balance, micro balance and ultra micro balance, moisture meter, etc.
1.The internal resistance and self consumption of the battery are small, so the standby battery time is long.
2.The battery pack has good security and long cycle life.
3. The battery volume is small, which can be customized for various special structures, so it is suitable for handheld instruments
