22 Years' Battery Customization

3.7V 1100mAh Lithium Polymer Battery For Moisture Meter

3.7V 1100mAh Lithium Polymer Battery For Moisture Meter
3.7V 1100mAh Lithium Polymer Battery For Moisture Meter
3.7V 1100mAh Lithium Polymer Battery For Moisture Meter
3.7V 1100mAh Lithium Polymer Battery For Moisture Meter

Product Detail

Product number: 36AQ504-01
Cell model:602338-3.7V/550mAh
Battery specification: 602338-1S2P/1100mAh/3.7V
Nominal voltage:3.7V
Nominal capacity:1100mAh
Charging voltage: 4.2V
Charging current: ≤500mA
Discharging current: 200mA
Maximum discharging current: 2A,3~4S
End-off voltage: 3.0V
Internal resistance: ≤100mΩ
Battery weight: 30g
Product dimension: 42*24*12.5(mm)
Charging temperature:0~45℃
Discharging temperature: -10~60℃
Storage temperature: -20~20℃ (less than 12 month)
Battery case: PVC
Lithium ion battery protection: short circuit protection, overcharge protection, over discharge protection, over current protection.
Application field: Analytical balance, precision balance, micro balance and ultra micro balance, moisture meter, etc.


Product features
1.The internal resistance and self consumption of the battery are small, so the standby battery time is long.
2.The battery pack has good security and long cycle life.
3. The battery volume is small, which can be customized for various special structures, so it is suitable for handheld instruments

*
*
*
