Product number: 41DZ012-01
Cell model: INR18650-35E/3350mAh/3.6V
Battery specification: 6.4AH-10.8V
Nominal voltage: 10.8V
Nominal capacity: 6.4Ah
Charging voltage: 12.6V
Charging current: ≤3.2A
Discharging current: 3.2A
Instantaneous discharge current: 6.4A
Discharge cut-off voltage: 8V
Finished product internal resistance: 150 mΩ or less
Battery weight: 400g
Product dimension: 154.65×59×22.2mm (L×W×H)
Charging temperature: 0 ~ 45℃
Discharging temperature: -20 ~ 55℃
Storage temperature: -20 ~ 45℃
Battery case: Industrial grade
Lithium battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, equilibrium, Smbus communication, etc.
1.Maximum sustainable 6.4 A discharge.
2.Adopt imported software management chip, Smbus communication function, accurate data transmission, precise temperature control, so as to eliminate safety hidden trouble.
3.Adopt high capacity 18650 super reliable and safe batteries.
4.The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
