Custom Lithium ion Battery Pack

18650 25.2V 40Ah Low Temperature Battery for Instrument

Product Detail

Product number: 01WQ0049-01

Cell model:18650-3.6V-2.5Ah

Battery specification: 18650-7S16P-40Ah-25.2V

Nominal voltage:25.2V

Nominal capacity:40Ah

Charging voltage: 29.4V

Charging current: ≤8A

Discharging current: 25A continuous;40A instant

Instant discharging current: 40A

End-off voltage: 21V (17.5V at low temperature -40℃)

Internal resistance: ≤120mΩ

Battery weight: 6000g

Product dimension: 360.0×210.0×90.0(mm)±2mm

Charging temperature:0~45℃

Discharging temperature: -40~55 ℃

Storage temperature: -20~45℃

Battery case: general industrial grade

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection and overcurrent protection, etc.

Application field: instrument

Product features

1. Communication protocol: SMBUS communication protocol can transmit product data.

2. Cell characteristics: low temperature ternary battery pack

3. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
