Custom Lithium ion Battery Pack

11.1V 8000mAh Lithium Polymer Battery for Military Fiber Splicing Equipment

  • Model number:01DQ0096-02

  • Nominal voltage:11.1V

  • Nominal capacity:8000mAh

  • Battery cell:5245130/3.7V/4000mAh

  • Dimension:165.7*159.2*13.2mm(Max)

  • Application:industrial backup power

Product Detail

Product number: 01DQ0096-02

Cell model:5245130/3.7V/4000mAh

Battery specification: 5245130-3S2P/11.1V/8000mAh

Nominal voltage:11.1V

Nominal capacity:8000mAh

Charging voltage: 12.6V

Charging current: ≤4A

Discharging current: 4A

Instant discharging current: 8A

End-off voltage: 9V

Internal resistance: ≤200mΩ

Battery weight: 0.6Kg

Product dimension: 165.7*159.2*13.2mm(Max)

Charging temperature:0~45℃

Discharging temperature: -20~60℃

Storage temperature: -20~35℃

Battery case: ABS+PC

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, etc.

Application field: industrial backup power


Product features

1. Data communication management: adopt IC+TI software management chip, precise data transmission and accurate temperature control so as to try our best to eliminate the security risks.

2. The battery pack has good security, nice performance and long cycle life.

4. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.

*
*
*
