Application: industrial backup power
Product number: 31AQ049-01
Battery specification: 10S1P/25.6V/20Ah
Charging voltage: 29.2V
Charging current: ≤20A
Discharging current: 20A
Instant discharging current: 20A
End-off voltage: 20V
Internal resistance: ≤100mΩ
Battery weight: 27Kg
Product dimension: 440*280*243mm（Max）
Discharging temperature: -20～55℃
Storage temperature: -20～45℃
Lithium ion battery protection: short circuit protection, overcharging protection, over-discharging protection, overcurrent protection, equilibrium, RS485 communication, etc.
Application field: industrial backup power
1. Current: the maximum continuous discharging current is 20A.
2. Data communication management: adopt imported software management chip, 485 communicating function, precise data transmission and accurate temperature control so as to try our best to eliminate the security risks.
3. Battery feature: the battery has very long cycle life, which is 2000 cycles. It can keep charging and discharging under large power.
4. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
