Custom Lithium ion Battery Pack

26650 48V 40Ah LiFePO4 Battery for Industrial Backup Power with RS485 Communication

  • Model number:31AQ037-01

  • Nominal voltage:48.0V

  • Nominal capacity:40000mAh

  • Battery cell:26650/3200mAh/3.2V

  • Dimension:450*440*138.2MM(Max)

  • Application:industrial backup power

Product Detail

Product number: 31AQ037-01

Cell model:26650/3200mAh/3.2V

Battery specification: 26650-15S13P/48V/40Ah

Nominal voltage:48V

Nominal capacity:40Ah

Charging voltage: 54.75V

Charging current: ≤20A

Discharging current: 20A

Instant discharging current: 40A

End-off voltage: 30V

Internal resistance: ≤200mΩ

Battery weight: 17Kg

Product dimension: 450*440*138.2MM(Max)

Charging temperature:0~45℃

Discharging temperature: -20~55 ℃

Storage temperature: -20~45 ℃

Lithium-ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, equilibrium, communication with 232 and 485, etc.

Application field: industrial backup power


Product features

1. Current: maximum continuous discharge 40A

2. Data communication management: adopt imported software management chip, CAN communication function, precise data transmission and accurate temperature control so as to try our best to eliminate the security risks.

3. Battery characteristics: the battery pack has ultra-long cycle life, which can be 2000 cycles. It can also keep charging and discharging on large power.

3. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.

*
*
*
