Custom Lithium ion Battery Pack

18650 11.1V 4400mAh Ternary Battery Bak Battery

Product Detail

Product number : 05BQ1194-02

Combination mode: ICR18650-3S2P

Nominal voltage: 11.1V

Operating voltage: 7.2~ 12.6V

Nominal capacity: 4400mAh

Standard continuous discharge current: 0.2C

Maximum continuous discharge current: 1C

Operating temperature: Charging: 0~45℃

Discharge: - 20 ~ 60 ℃

Product dimension: MAX 39*57*70mm

Finished product internal resistance: 200 mΩ or less

Lead model: The lead of the battery output end is UL1007/20# red and black with a length of 200mm

Led low voltage indicator, UL1007/22# red and black, line length 250mm

Protection parameters: overcharge protection voltage / 4.35± 0.025V per series

Overdischarge protection voltage is 2.4± 0.08V

Overcurrent value: 7~10A

*
*
*
