Custom Lithium ion Battery Pack

26650 25.6A 60Ah LiFePO4 Battery for AGV with RS485 Communication Port

  • Model number:30AQ078-01

  • Nominal voltage:25.6V

  • Nominal capacity:60000mAh

  • Battery cell:26650/3.2V/3.5Ah

  • Dimension:304×243×152(Max)

  • Application:robot, AGV, RGV

Product Detail

Product number: 30AQ078-01

Cell model:26650/3.2V/3.5Ah

Battery specification: 26650/8S18P/25.6V/60Ah

Nominal voltage:25.6V

Nominal capacity:60Ah

Charging voltage: 29.2V

Charging current: ≤30A

Discharging current: 20A

Instant discharging current: 60A

End-off voltage: 20V

Internal resistance: ≤200m?

Product dimension: 304×243×152(Max)

Battery weight: 15kg

Charging temperature:0~45℃

Discharging temperature: -20~55 ℃

Storage temperature: -20~55 ℃

Temperature protection: 65℃±5℃

Battery case: cold rolling and metal plate

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection, equilibrium, etc.

Application field: robot, AGV, RGV


Product features

1. Shock-resistant and dustproof: fill in the shock-resistant structure inside with cold rolling metal plate on which spray the powder to satisfy the requirements of shock-resistant and dustproof.

2. Safety management of the battery: when the temperature probe of battery finds out over temperature status, the protection system is on automatically.

3. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.


*
*
*
