Custom Lithium ion Battery Pack

18650 10.8V 3350mAh Ternary Battery Samsung Battery

Product Detail

Product number: 08DQ0030-01

Cell model:INR18650-35E/3350mAh/3.60V

Battery specification: 18650-3S1P/10.8V/3350mAh

Nominal voltage:10.8V

Nominal capacity:3350mAh

Input voltage: 100-240Vac

Output voltage:8.1-16Vdc

Charging current: ≤1200mA

Discharging current: 0.5A

Instant discharging current: 1A

End-off voltage: 8.1V

Internal resistance: ≤250mΩ

Battery weight: about 550g

Product dimension: 162×82×63.5mm(L×W×H)

Charging temperature:0~45℃

Discharging temperature: -20~60℃

Storage temperature: -20~50 ℃

Battery case: industrial level

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, equilibrium, IIC communication, etc.

Application field: Communication,direct current UPS



Product features

1.Current/voltage: It has maximum sustainable discharge output 1A with solution integration management functions, which can realize charging and discharging at the same time. It is safe and reliable to realize seamless switching function.

2.Data communication management: It has imported software management chip, IIC communication function, accurate data transmission, precise temperature control, so as to eliminate safety hidden trouble.

3.Batteries features: Adopts imported 18650 ternary lithium batteries.

4.The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.

*
*
*
