Custom Lithium ion Battery Pack

25.9V 2200mAh 18650 low temperature lithium ion battery for low temperature detector

  • Model number:35AQ224-01

  • Nominal voltage:25.9V

  • Nominal capacity:2200mAh

  • Battery cell:18650/3.7V/2200mAh

  • Dimension:145*72*38mm(Max)

  • Application:low temperature tester

Product Detail

Product number: 35AQ224-01

Cell model:18650/3.7V/2200mAh

Battery specification: 18650-7S1P/25.9V/2200mAh

Nominal voltage:25.9V

Nominal capacity:2.2Ah

Charging voltage: 29.4V

Charging current: ≤1.0A

Discharging current: 1A

Instant discharging current: 2A

End-off voltage: 17.5V

Internal resistance: ≤500m?

Battery weight:320g

Product dimension: 145*72*38mm(Max)

Charging temperature:0~45℃

Discharging temperature: -40~60 ℃

Storage temperature: -20~35 ℃

Temperature protection: /

Battery case: /

Lithium ion battery protection: short circuit protection, overcharging protection, over-discharging protection and overcurrent protection.

Application field: low temperature tester

*
*
*
