Custom Lithium ion Battery Pack

11.1V 1800mAh low temperature li-polymer battery for wireless aviation controller with SMBUS communication

  • Model number:35AQ0011

  • Nominal voltage:11.1V

  • Nominal capacity:1800mAh

  • Battery cell:653370/1800mAh/3.7V

  • Dimension:100*80*8mm(Max)

  • Application:wireless aviation controller

Product Detail

Product number: 35AQ0011

Cell model:653370/1800mAh/3.7V

Battery specification: 653370-3S1P/1800mAh/11.1V

Nominal voltage:11.1V

Nominal capacity:1800mAh

Charging voltage: 12.6V

Charging current: ≤3A

Discharging current: 3A

Instant discharging current: 4A

End-off voltage: 7.5V

Internal resistance: ≤200mΩ

Battery weight: 300G

Product dimension: 100*80*8mm(Max)

Charging temperature:-20~45℃

Discharging temperature: -40~60 ℃

Storage temperature: -20~35 ℃

Temperature protection: 70℃±5℃

Battery case: engineering plastic, military standard

Lithium ion battery protection: short circuit protection, overcharging protection, over-discharging protection, overcurrent protection, temperature protection, equilibrium, etc.

Application field: wireless aviation controller



Product features

1. Metal output terminal: adopt Gold-plated shrapnel so as to strengthen the stability of conductivity.

2. Battery: adopt low temperature battery, which can discharge at -40℃.

3. Data communication management: adopt IC+TI software management chip, precise data transmission and accurate temperature control so as to try our best to eliminate the security risks.

4. The battery pack has good safety performance, nice low temperature performance and long cycle life.

5. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.

*
*
*
