Custom Lithium ion Battery Pack

10.8V/6.7Ah Panasonic Battery Ternary Battery for BRJ-R

Product Detail

Product number: 37AQ050-01

Cell model:NCR18650B/3.6V/3.35Ah

Battery specification: 18650/3S2P/10.8V/6.7Ah

Nominal voltage:10.8V

Nominal capacity:6.7Ah

Charging voltage: 12.6V

Charging current: ≤2A

Discharging current: 2A

Instant discharging current: 4A

End-off voltage: 7.5V

Internal resistance: ≤250mΩ

Battery weight: 300g

Product dimension: 65×43×75(Max)

Charging temperature:0~45℃

Discharging temperature: -20~50 ℃

Storage temperature: -20℃~20℃

Battery case: PVC

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection and overcurrent protection.

Application field: BRJ-R

Product features

1. Low self-discharge.

2. The battery pack has good security and long cycle life.

3. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.

4. It has holder, epoxy plate and safety protection circuit.
