LiFePO4 Battery of 76.8V for 10Ah Communication Room with RS485 Communication Port

Product Detail

Product number: 04EQ053-01

Cell model:1565151/3.2V/10Ah

Battery specification: 1565151/24S1P/76.8V/10Ah

Nominal voltage:76.8V

Nominal capacity:10Ah

Charging voltage: 87.6V

Charging current: ≤5A

Discharging current: 10A

Instant discharging current: 15A

End-off voltage: 60V

Internal resistance: ≤380m?

Battery weight: 11kg

Product dimension: 441×415×88.9(Max)

Charging temperature:0~45℃

Discharging temperature: -20~55 ℃

Storage temperature: -20~40 ℃

Temperature protection: 65℃±5℃

Battery case: cold rolling and metal plate

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, equilibrium, etc.

Application field: communication room, emergency power supply

Product features

1. Capacity display: show the battery status and capacity directly by LED.

2. Waterproof aviation connector: apply waterproof aviation connector, which is safe and reliable.

3. Communication interface: have RS485 communication protocol and can read the information of battery voltage, current, temperature, capacity, etc.

4. Data communication management: adopt software management chip, precise data transmission and accurate temperature control so as to try our best to eliminate the security risks.

5. Safety management of the battery: when the temperature probe of battery finds out over temperature status, the protection system is on automatically.

6. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
