Application:intelligent robot, robotic arm, etc.
Product number: 03EQ023-01
Battery specification: 18650-7S5P/24V/13Ah
Charging voltage: 29.4V
Charging current: ≤3A
Discharging current: 2.6A
Instant discharging current: 5A
End-off voltage: 17.5V
Internal resistance: ≤150mΩ
Battery weight: 1700g
Product dimension: 150*101*70mm（Max）
Discharging temperature: -20～60℃
Storage temperature: -20～60℃
Temperature protection: 65℃±5℃
Battery case: PVC
Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection, I2C communication, etc.
Application field: intelligent robot, robotic arm, etc.
1. Data communication management SMBUS: adopt TI software management chip, and IC monitors the temperature, voltage, capacity, percentage, etc. of the battery pack.
5. The host machine transmits the data by SMBUS to know the information of battery pack so as to improve the security.
6. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
