18650 3.6V 2.5Ah Power Battery Lishen Battery for Handheld Massager

18650 3.6V 2.5Ah Power Battery Lishen Battery for Handheld Massager
18650 3.6V 2.5Ah Power Battery Lishen Battery for Handheld Massager
18650 3.6V 2.5Ah Power Battery Lishen Battery for Handheld Massager
18650 3.6V 2.5Ah Power Battery Lishen Battery for Handheld Massager

Product Detail

Product number: 36AQ076-02

Cell model:18650/3.6V/2.5Ah

Battery specification: 18650/4S1P/14.4V/2.5Ah

Nominal voltage:14.4V

Nominal capacity:2.5Ah

Charging voltage: 16.8V

Charging current: ≤1A

Discharging current: 2.5A

Instant discharging current: 7.5A

End-off voltage: 10V

Internal resistance: ≤250mΩ

Battery weight: 600g

Product dimension: 160×49.6×30.6(Max)

Charging temperature:0~45℃

Discharging temperature: -40~60 ℃

Storage temperature: -20~20 ℃

Temperature protection:/

Battery case: PC

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection and overcurrent protection.

Application field: medical device, massage equipment


Product features

1. Shock-resistant and waterproof: fill in the shock-resistant structure inside the cold rolling metal plate housing to satisfy the requirements of good security and high reliability.

2. Large current operation: adopt high rate power to make sure work under large current.

3. Reliable connection: apply square sheet, which is efficient, safe and reliable.

4. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.


*
*
*
