3.7V 1000mAh Lithium Ion Battery for Monitor

Product Detail

3.7V 1000mAh Lithium Ion Battery for Monitor

Product number: 01CQ0010-01

Cell model:523450/3.7V/1000mAh

Battery specification: 523450-1S1P/3.7V/1000mAh

Nominal voltage:3.7V

Nominal capacity:1000mAh

Charging voltage: 4.2V

Charging current: ≤500mA

Discharging current: 500mA

Instant discharging current: 1.0A

End-off voltage: 3.0V

Internal resistance: ≤300mΩ

Battery weight: 22g

Product dimension: 53*34.5*6.0mm(Max)

Charging temperature:0~45℃

Discharging temperature: -20~60 ℃

Storage temperature: -20~35 ℃

Battery case: PVC

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, etc.

Application field: monitor, test and control instrument
