Product number: 03DQ0078-04T
Battery specification: 18650-1S1P/2600mAh/3.6V
Product dimension: 68.5*37.5*19.5mm（Max）
Charging voltage: 4.2V
Charging current: ≤1.3A
Discharging current: ≤2.6A
End-off voltage: 3.0V
Internal resistance: ≤180mΩ
Battery weight: 60g
Discharging temperature: -20～60℃
Storage temperature: -20～35℃
Battery case: blue PVC heat shrinkable film
Lithium ion battery protection: short circuit protection, overcharge protection, over discharge protection, over current protection, ESD protection, etc.
Application field: Bluetooth speakers, speakers and other portable devices
1.Blue PVC heat shrinkable film package is simple and reliable, and it is easy to install.
2.Connector plug outlet: MOLEX plug output mode is adopted to increase the conductive reliability of the plug.
3.Battery protection management: Use imported Seiko protection chip with high stability, high precision monitoring, precise control, ESD protection and temperature Protection, which can eliminate the potential safety hazard to the maximum extent.
4.The battery pack has good security, nice discharge performance and long cycle life.
5.The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
