Product number: 37DZ033-01
Cell model：18650 3.6V/2.1Ah
Battery specification: 4S1P/14.4V/2.1Ah
Charging voltage: 16.8V
Charging current: ≤1A
Discharging current: 10A
Instant discharging current: 30A
End-off voltage: 11V
Internal resistance: ≤150mΩ
Battery weight: 200g
Product dimension: 37*41*135 mm（Max）
Discharging temperature: -20～60 ℃
Storage temperature: -20～45 ℃
Temperature protection: 65℃±5℃
Lithium-ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection, etc.
Application field: backup battery of lottery printer
1. 5C discharge
2. Temperature protection
3. Battery pack has good security and long cycle life.
4. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
