Product number: 30AQ188-03
Battery specification: 36650-6S4P/19.2V/14Ah
Charging voltage: 21.9V
Charging current: ≤5A
Discharging current: 5A
Instant discharging current: 10A,3~4S
End-off voltage: 15V
Internal resistance: ≤150mΩ
Battery weight: 2Kg
Product dimension: 140*110*95（mm）
Discharging temperature: -20～60℃
Storage temperature: -20℃～+23℃（≤12months）
Battery case: PVC plain packaging
Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection and 485 communication, etc.
Application field: medical device backup battery
1. Low self-discharge.
2. The battery pack has good security and long cycling life.
3. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
4. Battery shape can be customized, and the battery has anti - reverse - connection function.
5. It can accurately detect battery information with communication.
