22 Years' Battery Customization

18650 3.63V 15.6Ah Samsung Battery 18650 Battery for Muscles Therapy Apparatus

18650 3.63V 15.6Ah Samsung Battery 18650 Battery for Muscles Therapy Apparatus
18650 3.63V 15.6Ah Samsung Battery 18650 Battery for Muscles Therapy Apparatus
18650 3.63V 15.6Ah Samsung Battery 18650 Battery for Muscles Therapy Apparatus
18650 3.63V 15.6Ah Samsung Battery 18650 Battery for Muscles Therapy Apparatus

Product Detail

Product number: 01WQ0033-01

Cell model:ICR18650-26JM/2600mAh/3.63V

Battery specification: 18650-6P/15.6Ah/3.63V

Nominal voltage:3.63V

Nominal capacity:15.6Ah

Charging voltage: 4.2V

Charging current: 3120mA

Discharging current: 3120mA

Maximum discharging current: 8000mA

End-off voltage: 3.0V

Internal resistance: ≤150mΩ

Battery weight: 400g

Product dimension: 1.82.3*64.3*38.3mm(Max)

2. 82.3*64.3*55.4mm(Max)

The special shape battery housing has a gradient.

Charging temperature:10~45℃

Discharging temperature: -20~60℃

Storage temperature: -20~45℃ less than three months

Battery package: PC housing

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection and overcurrent protection.

Application field: medical device, muscles therapy apparatus


Product features

PC shell increases the reliability of the battery and solidity.

Output terminal of connector: adopt gold-plated shrapnel output mode to increase conductive reliability and stability.

Battery management: adopt imported protective chip, which has good stability, high precision monitoring, accurate control with ESD protection and temperature protection, so as to eliminate the security risks.

The battery pack has good security, nice performance and long cycle life.

The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.

*
*
*
