Product number: 05DQ0046-01
Battery specification: 18650-2S2P-6100mAh-7.2V
Product dimension: 75*71*19.5mm（Max）
Charging voltage: 8.4V
Charging current: ≤3A
Discharging current: ≤3A
End-off voltage: 6.0V
Internal resistance: ≤180mΩ
Battery weight: 210g
Discharging temperature: -20～60℃
Storage temperature: -20～35℃
Battery case: blue PVC heat shrinkable film
Lithium ion battery protection: short circuit protection, overcharge protection, over discharge protection, over temperature protection, over current protection, ESD protection, etc.
Application field: portable network cable detector and other portable test equipment.
1.Battery management: Use imported protection chip with high stability, high precision monitoring, precise control, ESD protection, temperature protection and other functions, which can maximize the elimination of security risks.
2.The battery pack has good security, nice discharge performance and long cycle life.
3.The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
4.Blue PVC heat shrinkable film package is simple and reliable, and it is easy to install.
5.Connector plug: JST plug output mode is adopted to increase conductive reliability.
