10.8V 3350mAh Samsung 18650 High Rate Battery For Encoder With SMBUS Communication protocol

Product Detail

Product number: 08DQ0022-01
Cell model:18650-3350mAh-3.6V
Battery specification: 18650-3S1P-3350mAh-10.8V
Product dimension: 72*56*20mm(Max)
Nominal voltage:10.8V
Nominal capacity:3350mAh
Charging voltage: 12.6V
Charging current: ≤1.6A
Discharging current: ≤8A
End-off voltage: 8.4V
Internal resistance: ≤180mΩ
Battery weight: 170g
Charging temperature:0~45℃
Discharging temperature: -20~60℃
Storage temperature: -20~35℃
Battery case: blue PVC heat shrinkable film
Lithium ion battery protection: short circuit protection, overcharge protection, over discharge protection, over current protection, ESD protection, etc.
Application field: encoder, portable handheld device.


Battery feature
1.Battery protection management: Adopt imported protection chip with high stability, high precision monitoring, precise control, which can maximize the elimination of security risks.
2.Data communication management: Adopt TI-SMBus software management chip, SMBus communication precise data transmission and precise temperature control, which can eliminate the potential safety hazard to the maximum extent.
3.The battery pack has good security, nice discharge performance and high rate. It can support 3C rate discharge, and the discharge capacity can reach more than 90%.
4. The battery pack has good security, nice discharge performance and long cycle life.
5.The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
6.Blue PVC heat shrinkable film package is simple and reliable, and it is easy to install.
7.Connector plug: JST plug output mode is adopted to increase conductive reliability

*
*
*
