Product number: 04DQ0090-01
Battery specification: 18650-4S3P/7800mAh/14.4V
Charging voltage: 16.8V
Charging current: 1500mA
Discharging current: 1500mA
Maximum discharging current: 7500mA
End-off voltage: 10.0V
Internal resistance: ≤200mΩ
Battery weight: 800g
Product dimension: 150.5*60.5*41.3mm（Max)
Discharging temperature: -40～60℃
Storage temperature: -20～60℃ (less than a month)
Battery case: ABS+PC
Lithium ion battery protection: short circuit protection, overcharge protection, over discharge protection, over current protection, etc.
Application field: Outdoor equipment and testing equipment
1.Battery management: using TI charging management chip with high stability, high precision monitoring, precise control, temperature protection and other functions, which can eliminate the potential safety hazard to the maximum extent.
2.ABS+PC housing increases the reliability and firmness of the battery.
3.Data communication management: with communication transmission, accurate data transmission, precise temperature control, real-time battery condition monitoring and control.
4.It can discharge at a minimum temperature of - 40 ℃.
5.Outlet of connector plug: TSA0 plug output mode is adopted to increase the conductive reliability of the plug.
6. The battery pack has good security and nice performance.
7. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
