Product number: 36AQ416-01
Battery specification: 18650-4S2P/14.4V/6.7Ah
Charging voltage: 16.8V
Charging current: ≤3.3A
Discharging current: 1.5A
Instant discharging current: 5A,3~4S
End-off voltage: 12V
Internal resistance: ≤280mΩ
Battery weight: 450g
Product dimension: 142.48*41.5*41.5（mm）
Discharging temperature: -10～60℃
Storage temperature: -20～23℃ (less than 12 month)
Battery case: ABS+PC
Lithium ion battery protection: normal protection + SMBUS communication protocol
Application field: rugged laptop, industrial instrument.
1. Imported cell: The battery pack has good security and long cycle life.
2. The battery is intelligent with SMBUS communication protocol, and the protection parameters can be adjusted by software.
3.Special shape design: the battery can be customized for various special structures, and the battery shell is removable and easy to replace.
4.The battery adopts anti drop design.
