22 Years' Battery Customization

18650 10.8V 3350mAh Bladder Test Battery

18650 10.8V 3350mAh Bladder Test Battery
18650 10.8V 3350mAh Bladder Test Battery
18650 10.8V 3350mAh Bladder Test Battery
18650 10.8V 3350mAh Bladder Test Battery

Product Detail

Product number: 01WQ0021-04T

Battery model: 18650-3350mAh-3.6V

Battery specification: 18650-3S1P-3350mAh-10.8V

Product size: 72*57*20mm (Max)

Nominal voltage: 10.8V

Nominal capacity: 3350mAh

Finished internal resistance: ≤180mΩ

Charging voltage: 12.6V

Charging current: ≤1.5A

Discharge current: ≤3.3A

Discharge cut-off voltage: 8.4V

Battery weight: 170g

Charging temperature: 0 ~ 45℃

Discharge temperature: -20 ~ 60℃

Storage temperature: -20 ~ 35℃

Battery package: Blue PVC heat shrink film

Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overtemperature protection, overcurrent protection,ESD protection, etc.

Application: bladder testing instrument, portable medical equipment

Product Features

1.Blue PVC heat shrink film package is simple and reliable,and easy to install;

2.The battery pack is connected with special nickel sheet, which has good shock resistance;

3.Connector plug output terminal: Use MOLEX plug output mode to increase the electrical reliability of the plug;

4.Battery protection management: Use special lithium-ion battery protection chip, with high stability, high precision monitoring, accurate control, temperature protection and other functions,to maximize the elimination of safety hazards;

5.Data communication management: TI-SMBus software management chip, SMBus communication accurate data transmission, real-time battery status monitoring and control.

6.The battery pack has nice safety, good discharge performance and long cycle life;

7.The battery pack has long cycle life, in line with low carbon, energy saving, environmental protection value concept;
