18650 7.2V 6700mAh Samsung Battery for Surveying Instrument
Product Number:
05BQ673-40
Nominal voltage:
7.2V
Nominal capacity:
6700mAh
Battery Configuration:
18650-2S2P
Dimension:
21 × 66 × 68mm
Application:
surveying and mapping instruments
High Capacity Design, Intelligent Protection System, USB Charging Support
Product Overview
This battery is designed for surveying and mapping instruments, supporting long-term outdoor measurement and high-load operating scenarios. With stable power output and high-capacity performance, it ensures reliable continuous operation in demanding field environments.
Electrical Specifications
| Attribute | Parameter |
|---|---|
| Product Number | 05BQ673-40 |
| Cell Model | 18650/3350mAh/3.6V |
| Battery Configuration | 18650-2S2P |
| Nominal Voltage | 7.2V |
| Nominal Capacity | 6700mAh |
| Rated Energy | 48.24Wh |
| Discharge Cut-off Voltage | 5.5V |
| Standard Charging Current | ≤3.9A |
| Standard Discharge Current | 4.0A |
| Max Continuous Discharge Current | 6A |
| Internal Resistance | ≤100mΩ |
Mechanical & Environmental
| Attribute | Parameter |
|---|---|
| Charging Temperature | 0 ~ 45℃ |
| Discharge Temperature | -20 ~ 60℃ |
| Storage Temperature | -20 ~ 20℃ |
| Dimensions | 21 × 66 × 68mm |
| Weight | 230g |
| Battery Case | ABS+PC |
| Protection System | Power Calculation, Short Circuit Protection, Overcharge Protection, Over Discharge Protection, Over Current Protection, USB Charging |
We support flexible customization based on your project requirements, including:
- Voltage range: 3.2V – 72V
- Capacity range: 100mAh – 100Ah
- Electrical performance design: Charge/discharge parameters, C-rate, internal resistance, temperature performance
- Mechanical design: Appearance, dimensions, housing material, and integrated structural engineering
- BMS design: Battery protection, cell balancing, and communication protocols (SMBus / I2C / UART)
Get a Custom Battery Solution
Tell us about your project needs. Our engineers will provide a tailored battery solution and quotation within 24 hours.
