Product number: 01WQ0087-01
Cell model: 18650-2550mah /3.6V
Specification: 18650-3S2P-5.1 AH-10.8V
Product size: 113 mm *72 mm *20.5mm (Max)
Nominal voltage: 10.8V
Nominal capacity: 5.1Ah
Charging voltage: 12.6V
Charging current: ≤ 2.6a
Discharge current: ≤ 5.2a
Discharge cut-off voltage: 8.25V
Product internal resistance: ≤200m ω
Battery weight: 320G
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60 ℃
Storage temperature: -20~+60℃ (less than 1 month) -20~ 45 ℃(less than 3 months); -20~+30℃ (less than 12 months)
Battery package: PVC
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, etc.
Application: Portable massager
1.PVC process is simple, reliable and easy to be installed.
2.Onput terminal: Adopt GB UL wire output mode to increase conductive reliability.
3.Battery protection management: Adopt imported well-known protection chips with good stability, high precision monitoring and precise control, to eliminate safety risks to the maximum.
4.The battery pack has good safety, nice discharge performance and long cycle life.
5.The battery pack has a long cycle life and conforms to the values of low-carbon, energy saving and environmental protection.
