How to Charge A Dead Lithium-Ion Battery - Charging And Reviving?

May 23, 2020   Pageview:182

Lithium-ion batteries are incredibly useful in today's electronic world. We use them at home, work, school, on our portable devices, among many other places.

However, unlike dry cells, they are much more expensive and cost a lot to replace. Sometimes, the battery can be revived if it is not charging or performing as needed.

This guide will give you all the information you need about why Li-ion batteries can suddenly become unresponsive and how you can restore them.

1.Can You Revive A Dead lithium-ion battery?

Yes, depending on the issue at hand. Lithium batteries are susceptible to several problems that can lead to them becoming unresponsive to charging or discharging.

To understand how you can revive a dead lithium-ion battery, you have to look into how it works and its unique features.

How lithium-ion batteries Work

The term 'lithium-ion battery' is a blanket term that refers to many types of batteries that rely on lithium ions to work. Their common feature is that they rely on an anode(positive terminal) made out of a lithium compound.

During charging, positively charged lithium ions move across the electrolyte to the cathode (negative terminal). In return, negatively charged ions are released from the cathode and move the anode.

The reverse happens when discharging, where the lithium ions move towards the anode. The problem is that if the battery is discharged for too long, the electrodes can be excessively stripped of ions.

If, after such a state of discharge, you attempt to recharge the battery, the electrodes are reconstituted. This process is very irregular and can easily cause short circuits, fires, and explosions.

To prevent this from occurring, lithium-ion batteries are equipped with a battery management system (BMS) that measures the health of the battery based on its voltage.

24V Emergency Starting Power Supply,Low Temperature Large Current
Low Temperature Large Current 24V Emergency Starting Power Supply Battery specification: 25.2V28Ah (lithium battery) , 27V300F (supercapacitor pack) Charging temperature:-40℃~+50℃ Discharging temperature: -40℃~+50℃ Starting current: 3000A

What Causes a Dead, Sleeping, or Bricked Battery

If the BMS detects the battery voltage to be below a predetermined level, it will not charge it for safety purposes. That is why even if you plug it in, it does not charge and can also display a faulty battery indicator LED.

This is what, in most cases, causes a sleeping battery. Such a battery can be revived if:

●It is not below the nominal voltage. For a 3.2 or 4V battery pack, this is usually 1.5V.

●It has been below the nominal voltage for less than a week.

●It shows no signs of physical damage.

While you can revive such a battery to its operational state, be aware that the process can be dangerous. In most cases, you will be voiding your warranty with the manufacturer.

You should return such a battery for recycling and buy a new one. However, if you still want to revive it yourself, there are a few tricks you can use.

2.How Do You Charge A Battery That Is Completely Dead?

There are two ways you can revive a dead lithium-ion battery. The first involves its original charger or other approved models, while the second consists of another battery of similar voltage and capacity.

Reviving a Dead Li-Ion Battery Using a Booster Charger

If the battery comes with a separate AC charger or charging dock, check with the manufacturer that it has a ‘boost’ function.

This is a feature where the charger checks the battery to see whether it is above nominal voltage. If not, it applies an appropriate voltage to restore it to acceptable levels.

Different manufacturers incorporate various functionalities in these chargers. They will typically display light to show if the battery is charging. For some, you might need to manually change between ‘normal’ and ‘boost’ charging.


Give the battery 3 hours in 'boost' charging and 2 hours in 'normal' charging. Then connect it to a high load such as a power tool or flashlight until it discharges fully, then charges it normally.

If the charger has an automatic boost mode, let the battery charge to halfway full, discharge it, then recharge it normally.

Low Temperature High Energy Density Rugged Laptop Polymer Battery 11.1V 7800mAh
Low Temperature High Energy Density Rugged Laptop Polymer Battery Battery specification: 11.1V 7800mAh -40℃ 0.2C discharge capacity ≥80% Dustproof, resistance to dropping, anti - corrosion, anti - electromagnetic interference

Reviving a Dead Li-Ion Battery Using Another Battery

You can also use a similar charged battery to ‘jumpstart’ the dead one. Here is what you should do.

●Find a similar battery with a matching voltage and almost similar charge capacity.

●Make sure the other battery has sufficient charge. It should have a higher voltage.

●Connect the two batteries with cables. The two positive terminals should match, same with the negative ones.

●Let them sit for 5-10 minutes, then disconnect the cables.

●Check that the previously depleted battery is now above minimum voltage, then charge it as usual.

What happens here is that as the batteries equalize their charges, the one with the higher voltage directly boosts the one with a lower one. Once the voltage is above the minimum, it can be recharged normally with a charger.

3.How Do You Extend Your lithium ion battery Life?

Lithium batteries degrade over time, just all other types of batteries. This process can, however, be slowed down by taking a few precautions. That way, you can increase the service life of your lithium battery.

●Avoid deep charging cycles. Unlike NiCad batteries, lithium-ion batteries lack the 'memory' effect. Deep charging uses up their life cycles faster while replenishing them from, say, 50% of charge helps improve it.

●Maintain low temperatures. Lithium batteries love the cold, and while heat tends to degrade them. If your device lacks thermal protection, make sure to cool it down regularly.

●If your battery seems to have reduced its capacity significantly, wrap it in a watertight Ziploc bag and freeze for 24 hours. After that, thaw it for 8 hours and recharge it fully.

●Always use recommended or manufacturer-provided chargers.

●Do a full recharge now and then. That means you completely drain the battery, then recharge it fully using a recommended charger.

●Keep track of shelf life. Even when a lithium battery is not in use, it still degrades with time because Li-ion batteries have a limited life of 5 to 10 years. Also, make sure that when you buy them, they have been on the shelf for too long.

Just like any other battery or electronic device, the key to increasing the service life of your lithium-ion battery is to take proper care of it.

Final Words

It is easy and economical to restore a dead lithium battery to full operation. However, it can be dangerous for some batteries. If the battery you want to restore has been under storage for long, it is not worth the risk involved. Just recycle it and buy a new one.

It is always recommended that you recycle and replace a dead lithium battery instead.
