Determine the Terminal Voltage of the Top Battery- Introduction, Formula, and Calculation

Jul 22, 2021   Pageview:52

While most of us are using the batteries without even knowing how their internals work, things get very interesting when you get to know about the specific terms and internal characteristics of the battery. One of these terms or the most significant property of the battery is the terminal voltage.

24V Emergency Starting Power Supply,Low Temperature Large Current
Low Temperature Large Current 24V Emergency Starting Power Supply Battery specification: 25.2V28Ah (lithium battery) , 27V300F (supercapacitor pack) Charging temperature:-40℃~+50℃ Discharging temperature: -40℃~+50℃ Starting current: 3000A

Whenever some product is designed that uses a battery there are a lot of things that are considered during the designing process. One of those is the terminal voltage of the battery. So, if you are looking to learn more about the terminal voltage of the battery then you are at the right place. Here we will be discussing all the terminal voltage of the battery, its formula, calculation, significance, and a lot more.

The Terminal Voltage of a battery is given in which unit?

When it comes to using the batteries for any application that includes precise measurements, one of the most important things that are considered is terminal voltage. Before starting about the unit of terminal voltage it is better to have a general overview of this term for a better understanding.

What is the terminal voltage of a battery?

When you have a battery sitting in an idle condition with no load or source of power connected to its terminals then the voltage across its terminals will be the terminal voltage. Speaking of the terminal voltage, the ideal battery for the system is the one that comes with the terminal voltage that stays constant.

This consistency is maintained independently of the current flowing between the two terminals. It means that as long as the resistance in the system and the current through the circuit will not change the terminal voltage can be kept constant.

The Unit for Terminal Voltage

Now that you have a better idea of what terminal voltage is, it will be meaningful to know about the unit of measuring the terminal voltage along with its significance. So, the unit used for measuring the terminal voltage is “Volts”. One important thing to consider here is that it is not the same as the potential difference as the terminal voltage is not a force.

Low Temperature High Energy Density Rugged Laptop Polymer Battery 11.1V 7800mAh
Low Temperature High Energy Density Rugged Laptop Polymer Battery Battery specification: 11.1V 7800mAh -40℃ 0.2C discharge capacity ≥80% Dustproof, resistance to dropping, anti - corrosion, anti - electromagnetic interference

Voltage is often known as emf which means the potential difference between battery terminals when there is no flow of current.

Terminal Voltage Formula

The terminal voltage formula is a simple formula that includes 3 main factors and there is nothing else. However, starting the formula right away will not be meaningless unless you know the significance of the formula and how different factors participate in the formula. So, let us start with the formation of a system.

A simple system for measuring the terminal voltage of the battery consists of the following things:

The terminal voltage.

The internal resistance.

Emf of the battery.

When calculating the terminal voltage of the battery these are used in the following formula.

V = emf-Ir.

Here V stands for the terminal voltage, emf is the voltage of the battery with no current flowing through it and Ir stands for the internal resistance of the battery. As the calculation of the terminal voltage does not include considering any internal voltage the Ir or the internal resistance of the battery is subtracted from the equation to produce terminal voltage.

Although it is the formula for calculating the terminal voltage of the batteries and it is used in most cases, it is only applicable for the ideal systems of battery where the exact internal resistance is not to be considered.

When we talk about real-life issues neglecting the real internal resistance of the battery is not a case because there is no system known as the perfect system. It is the point that leads us to the next thing here which is calculating the terminal voltage of a battery with internal resistance.


Calculate the terminal voltage for a battery with internal resistance.

When we talk about real-life scenarios there are a lot of things that we need to consider. Although the formula for calculating the terminal voltage of the battery subtracts the internal resistance. It is not the right way to deal with things. There are a lot of factors that need to be considered when taking a look at the internal resistance of the battery.

Some Factors Affecting the Internal Resistance

One of the most important things about the batteries is the internal resistance and it is somewhat difficult to maintain as well. There are a lot of factors that affect the internal resistance of the battery and some of those factors are:

The magnitude of the current

The direction of the current flowing through the voltage source.

Temperature of the battery.

The environment around the battery.

Size of the battery and battery technology.

The history of how the battery has been used and a lot of other things.

How do you calculate the terminal voltage of a battery with an internal resistance?

If we take an example of calculating the terminal voltage of the batteries of the same voltage. The internal resistance, in either case, will be different. In this example of a truck battery and a bike battery, both will be providing 12 volts as a source however the internal resistance will most probably be smaller in the case of the truck battery.

So, when you are calculating the terminal voltage of the battery in any case the same formula will be used. However, here you need to be a little more careful about the internal resistance of the battery. When calculating the terminal voltage, you need to take the exact internal resistance of the battery and then subtract it from the result to get the right terminal voltage.

However, it is the case where you are dealing with real-life problems. In this way, you can easily calculate the terminal voltage of a battery with internal resistance.

Conclusion

The terminal voltage of a battery is one of the most important measurements as it tells about the battery in its idle state. Here we were discussing its significance and how you can calculate it in different scenarios.

*
*
*
