7.4V 4000mAh Lithium Ion Battery for Multi-function Scanning Terminal

Product Detail

7.4V 4000mAh Lithium Ion Battery for Multi-function Scanning Terminal


Product number: 22AQ123-01

Cell model:6247106/3.7V/4000mAh

Battery specification: 6248106/2S1P/7.4V/4000mAh

Nominal voltage:7.4V

Nominal capacity:4000mAh

Charging voltage: 8.4V

Charging current: ≤1000mA

Discharging current: 2000mA

Instant discharging current: 3000mA

End-off voltage: 6.0V

Internal resistance: ≤200mΩ

Battery weight: 170g

Product dimension: 110*50*13mm(Max)

Charging temperature:0~45℃

Discharging temperature: -20~60 ℃

Storage temperature: -20~35 ℃

Battery case: high temperature tape

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, etc.

Application field: Multi-function scanning terminal, test and control instrument


*
*
*
