Product number: 04EQ070-01
Battery specification: 18650/7S4P/24V/13Ah
Nominal voltage：24V stable voltage
Charging current: ≤6A
Discharging current: 10A
Instant discharging current: 15A
End-off voltage: 24V stable voltage
Internal resistance: ≤250m?
Product dimension: 170×130×85（Max）
Discharging temperature: -20～60 ℃
Storage temperature: -20～40 ℃
Battery case: cold rolling and metal plate
Lithium ion battery protection: short circuit protection, overcharging protection, over-discharging protection and overcurrent protection.
Application field: laser device
1. Shock-resistant and waterproof: fill in the shock-resistant structure inside the cold rolling metal plate housing to satisfy the requirements of good security and high reliability.
2. Output under stable voltage: output 24V stable voltage by DC-DC electric circuit to assure the power requirement of precision equipment.
3. Fast connect: apply push-pull self-locking aviation connector, which is efficient, safe and reliable.
4. Capacity display: show the remaining capacity of the battery directly by 4 LED light.
5. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
