18650 12.8V 1600mAh LiFePO4 Battery for Electric Power Monitoring

18650 12.8V 1600mAh LiFePO4 Battery for Electric Power Monitoring
18650 12.8V 1600mAh LiFePO4 Battery for Electric Power Monitoring
18650 12.8V 1600mAh LiFePO4 Battery for Electric Power Monitoring
18650 12.8V 1600mAh LiFePO4 Battery for Electric Power Monitoring

Product Detail

Product number: 34AQ020-08

Cell model: 18650-1600mAh-3.2V

Battery specification: 18650-4S1P-1600mAh-6.4V

Product size: 75*72*19.5mm (Max)

Nominal voltage: 12.8V

Nominal capacity: 1600mAh

Internal resistance of finished product: ≤220mΩ

Charging voltage: 14.4V

Charging current: ≤0.7A

Discharge current: ≤4.0A

Discharge cut-off voltage: 10.0V

Battery weight: 200g

Charging temperature: 0 ~ 45℃

Discharge temperature: -20 ~ 60℃

Storage temperature: -20 ~ 35 ° C

Battery package: Blue PVC heat shrinkable film

Output mode: national standard wire

Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection,ESD protection, etc

Application: Power monitor, security, instrumentation

*
*
*
*
*
