Product number: 41DZ010-01
Cell model: 26650-3400mAH-3.2V
Battery specification: 26650-8S10P-34AH-25.6V
Nominal voltage: 25.6V
Nominal capacity: 34Ah
Charging voltage: 29.2V
Charging current: ≤10A
Discharge current: 20A
Instant discharge current: 30A
Discharge cut-off voltage: 20V
Finished product internal resistance: ≤300mΩ
Battery weight: 10kg
Product dimension: length 513*210*90mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -10 ~ 60℃
Storage temperature: -20 ~ 45℃
Battery shell: industrial grade metal-plated shell
Lithium-ion battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, etc.
Application: outdoor computer equipment
1.Large current output: Copper nickel composite nickel strip is used to connect the cell, which can satisfy the charge and discharge of large current. It is safe and reliable.
2.Output aviation plug: Use aviation linker, which is safe and reliable, to meet the requirement of high current discharge;
3.Data communication management: Adopt imported high-precision BMS management chip, accurate protection parameter control, precise temperature control to eliminate security risks.
4.Battery characteristics: The cell has long life up to 2000 cycles, and can charge and discharge continuously with high power.
5.The battery has good safety with temperature probe. When the temperature exceeds, start protection automatically;
6.The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
